SEE PHOTOS
DESIGN:
Unmatched high speed capability achieved by the unique cutting geometry
Fast feed rates are possible due to the high performance tool geometry
2 precision ground cutting edges
Excellent chipflow and lower heat retention is provided by the semi-polished 2 flute design
Large clearance areas enable chips to quickly move away from cutting edges
Increased cutting edge durability from special submicron, extended life carbide
30° helix design with bottom cutting capability
APPLICATION:
For exceptionally smooth finishing cuts
For maximizing production with the highest feed-rates and longest tool life
Increased cutting edge life when frequently accelerating/decelerating or performing multiple passes
Eliminates chipping, fuzzing, and tear-out when the end of the upcut and downcut cutting edges are more than 1/16" from the top and bottom surfaces
When cutting rebates, dados, or pockets, use and upcut length that is at least 1/16" shorter than the shallowest cut
If part movement is a concern, use and upcut length of 4.8mm (0.188") or shorter
When possible select a router bit with a longer upcut length to improve chip ejection from cutting path
For improved dust extraction use with an Aerotech
MATERIALS:
Excellent finish on:
Laminated panels
HPL
Chipboard
MDF
Good finish on:
Softwoods and hardwoods
Plywood
OSB
LINEAGE XLC:
Extended life resharpenable coating
